Precision Manufacturing Services
1. Core Services
| Service | Technical Parameters/Details | Customer Value |
|---|---|---|
| CNC Turning | Accuracy: ±0.002mm Max. Diameter: Φ340mm Materials: Stainless Steel, Aluminum, Brass, etc. | – High-precision shafts/disks – Small to mass production |
| CNC Milling | 4/5-Axis Machining Positioning Accuracy: ±0.01mm Max. Travel: 1000×600×400mm | – Complex structures in one setup – Reduced re-clamping errors |
| Precision Drilling/Tapping | Hole Range: Φ0.5mm~Φ50mm Thread Accuracy: ISO Grade 2 Deep Hole (L/D≤10:1) | – High-accuracy threaded parts – Automotive/electronics applications |
| Sheet Metal Fabrication | Laser Cutting (±0.1mm) Bending Accuracy: ±0.2° Max. Thickness: 6mm (Stainless Steel) | – Custom enclosures/brackets – Rapid prototyping |
2. Technical Support
| Service | Details | Customer Value |
|---|---|---|
| DFM Analysis | – Free design optimization – Cost reduction up to 20% – 3D simulation | – Avoid production issues – Lower costs |
| Rapid Prototyping | – 3D Printing (SLS/SLA) – 48-hour sample delivery – Material options | – Faster development cycles – Design validation |
| Engineering Drawing Review | – ASME Y14.5 compliance – Tolerance analysis – Material substitution advice | – Production-ready drawings – Process optimization |
3. Stainless Steel Material Properties & Applications
| Grade | Characteristics & Processing | Mechanical Properties | Typical Applications |
|---|---|---|---|
| 303 | – Free-machining stainless steel (sulfur-added) – Suitable for high-speed turning – Moderate corrosion resistance |
– Tensile strength: ≥620 MPa – Hardness: HB 160-220 |
Bolts, nuts, bushings, and standard fasteners |
| 304 | – General-purpose austenitic stainless steel – Excellent corrosion resistance (food-grade) – Weldable/polishable |
– Tensile strength: ≥515 MPa – Elongation: ≥40% |
Food machinery, chemical pipelines, medical equipment housings |
| 316L | – Molybdenum-added, enhanced acid/alkali resistance – Suitable for marine environments – Electropolishable |
– Tensile strength: ≥485 MPa – Hardness: HRB 95 |
Marine fittings, pharmaceutical equipment, semiconductor components |
| 17-4PH | – Precipitation-hardening stainless steel – Hardness up to HRC 40+ after heat treatment – High strength & wear resistance |
– Tensile strength: ≥1100 MPa – Temperature resistance: ≤300°C |
Aircraft engine parts, high-strength gears |
Aluminum Alloy Properties & Applications
| Grade | Characteristics & Processing | Mechanical Properties | Typical Applications |
|---|---|---|---|
| 6061-T6 | – Most widely used structural alloy – Excellent weldability/anodizing results – Optimal strength-to-weight ratio |
– Tensile strength: ≥310 MPa – Hardness: HB 95 |
Automotive frames, drone components, heat sinks |
| 7075-T6 | – Ultra-high strength aerospace alloy – Hardness comparable to steel – Requires hard anodizing |
– Tensile strength: ≥570 MPa – Hardness: HB 150 |
Aircraft ribs, military parts, premium bicycle components |
| 5052-H32 | – High ductility & corrosion-resistant – Ideal for bending/stamping – Marine-environment suitable |
– Tensile strength: ≥230 MPa – Elongation: ≥12% |
Marine fittings, electronics enclosures, sheet metal chassis |
| A380 | – Die-casting optimized alloy – Superior flow characteristics – Cost-effective for mass production |
– Tensile strength: ≥320 MPa – Hardness: HB 80 |
Engine housings, power tool casings |
Copper Alloy Properties & Applications
| Grade | Characteristics & Processing | Mechanical Properties | Typical Applications |
|---|---|---|---|
| C11000 | – Pure copper (electrolytic tough pitch) – Excellent electrical/thermal conductivity (100% IACS) – Soft temper allows deep drawing |
– Tensile strength: ≥220 MPa – Conductivity: 101% IACS |
Electrical terminals, heat sinks, EMI shielding components |
| C36000 | – Free-cutting brass (lead-added) – High surface finish – Suitable for precision turning |
– Tensile strength: ≥340 MPa – Hardness: HB 100 |
Valve components, clock gears, plumbing hardware |
| C17200 | – Beryllium copper alloy – Heat treatable to HRC 38-42 – Exceptional elasticity/wear resistance |
– Tensile strength: ≥1100 MPa – Conductivity: 22% IACS |
Spring contacts, non-sparking tools, mold inserts |
| C46400 | – Naval brass (tin-added) – Superior seawater corrosion resistance – Weldable/forgeable |
– Tensile strength: ≥380 MPa – Elongation: ≥25% |
Marine propellers, offshore fasteners |
4. Surface Treatment Specifications
| Process Type | Technical Parameters/Test Standards | Application Scenarios |
|---|---|---|
| Anodizing | – Thickness: 10-50μm (custom colors) – Hardness: HV≥800 – Salt spray test: 1000h (ASTM B117) |
– Wear-resistant exterior parts – Electronics enclosures |
| Nickel Plating | – Layer thickness: 5-30μm – Porosity: ≤3 pores/cm² (ISO 4527) – Resistivity: 6.9μΩ·cm |
– Conductive/anti-corrosion components – Precision connectors |
| Sandblasting | – Grit size: 80#-240 (selectable) – Roughness: Ra0.8-3.2μm – Uniformity control: ±10% |
– Improving coating adhesion
– Matte surface finishing |
5.Quality Assurance & Testing Standards
| Inspection Item | Equipment/Standard | Compliance Standards |
|---|---|---|
| Dimensional Inspection | – CMM (Zeiss CONTURA) – Accuracy: 0.9μm+L/300 |
ISO 9001:2015 GD&T (ASME Y14.5) |
| Material Certification | – XRF Spectrometer (Olympus) – Composition Report (SGS/ROHS) |
ASTM E1251 EN 10204-3.1 |
| Mechanical Testing | – Universal Tester (Instron 300kN) – Tensile/Bend/Hardness Tests |
ASTM E8/E18 ISO 6892-1 |
6. Customer Service
| Service Item | Service Details | Customer Benefits |
|---|---|---|
| 24-Hour Quoting | – Instant online form (simple parts) – Complex project response ≤8hrs |
– Faster decision-making – Cost transparency |
| Global Logistics | – DHL/FedEx partnered channels – Export packaging (anti-rust/shock-proof) – Freight insurance available |
– Secure on-time delivery – Reduced shipping risks |
| After-Sales Support | – Quality issue response ≤48hrs – Free rework (within responsibility) – Ongoing technical consultancy |
– Supply chain stability – Continuous improvement |
7. Value-Added Services
| Service Item | Service Details | Customer Benefits |
|---|---|---|
| Prototype Production | – Free first articles (≤5pcs) – 30% discount on trial production |
– Lower new project risk – Validate mass production feasibility |
| VMI (Vendor Managed Inventory) | – Safety stock alert system – Weekly inventory reports (with turnover analysis) |
– Reduce inventory burden – Enable JIT supply |
| NDA Protection | – Encrypted drawing/data transfer – Dedicated production isolation area |
– IP protection – OEM security |
