Maozhong Precision focuses on UAV metal component manufacturing, with Swiss-type automatic lathe technology at its core, providing high-precision structural solutions for industrial-grade drones.
| Property | 7075-T6 | 6061-T6 | Best For |
|---|---|---|---|
| Tensile Strength | 570 MPa | 310 MPa | High-stress structural parts |
| Yield Strength | 480 MPa | 276 MPa | Motor mounts, arm connectors |
| Applications | Critical structural components | General brackets & housings | Based on load requirements |
| Traditional Machining | Swiss Lathe Process | Improvement |
|---|---|---|
| Multiple setups | Single setup completion | Eliminates cumulative error |
| ±0.05mm precision | ±0.01mm precision | 5x more accurate |
| High material waste | 90%+ material utilization | Cost reduction |
We support prototype orders from 1 piece and batch production from 500 pieces. For larger volumes, we offer tiered pricing discounts.
Three key measures: 1) Swiss-type lathes with thermal compensation systems, 2) CMM verification after each batch, 3) Strict temperature control in workshop (±2°C).
We accept STEP, IGES, X_T, SLDPRT, and DWG formats. For best results, please provide 3D files with 2D drawings including GD&T.
Challenge: Corrosion resistance in pesticide environment with vibration issues
Solution: 6061-T6 with hard anodizing (50μm thickness) + vibration damping design
Result: 3x longer service life, 40% weight reduction, zero corrosion after 2 years
If you are interested in this exceptional product, please feel free to contact us through the message box on the left side or the contact information provided below. We are eager to collaborate with you for a brighter future!
