Pneumatic hardware fittings are small yet crucial components used in air-powered systems. Their main purpose is to connect, redirect, or seal tubing and equipment in pneumatic circuits — ensuring efficient, leak-free air delivery. Choosing the right fittings plays a key role in system performance, durability, and safety.
Our company specializes in high-precision pneumatic fittings that are suitable for a wide range of industries, including:
🚗 Automotive and maintenance
🏭 Industrial automation
📦 Packaging and food processing
🤖 Robotics and assembly lines
🔬 Laboratory and testing equipment
| Fitting Type | Description | Typical Use |
|---|---|---|
| Straight Connectors | Direct connection between two tubes or ports | Air compressors, main pipelines |
| Elbow Connectors | Allows 90° or angled redirection of airflow | Compact machinery layouts |
| Tee & Y Fittings | Split or combine airflow paths | Multi-tool operations, air cylinder networks |
| Quick-Release Couplers | Fast and tool-free connection/disconnection | Portable air tools, repair garages |
| Threaded Adapters | Connect different thread types or sizes | NPT–BSP conversions, system upgrades |
| Swivel Joints | Allow rotation under air pressure | Dynamic hoses, robotic arms |
To ensure resistance to wear, corrosion, and extreme working conditions, our pneumatic fittings come with a variety of professional surface treatments:
| Surface Treatment | Description | Advantages | Typical Materials Applied On |
|---|---|---|---|
| Nickel Plating | Thin layer of nickel coating | Corrosion resistance, shiny finish | Brass, steel |
| Chrome Plating | Thick, polished chrome coating | High hardness, wear-resistant, mirror-like | Brass, stainless |
| Anodizing | Electrochemical process for aluminum | Color options, surface hardness | Aluminum alloy |
| Passivation | Acid treatment to remove contaminants | Improves stainless steel’s corrosion resistance | Stainless steel |
| Zinc Plating | Electroplated zinc layer | Low-cost anti-rust coating | Steel |
🛡️ These finishes not only enhance the appearance but also improve mechanical and chemical resistance in demanding industrial environments.
We offer fittings made from:
Brass – Affordable, anti-rust, suitable for dry air
Stainless Steel (304/316) – Hygienic, anti-corrosive, high strength
Aluminum Alloy – Lightweight and cost-effective
PBT / PA Plastic – Ideal for low-pressure, temporary, or lightweight systems
Need food-grade or chemical-grade materials? We support FDA-compliant stainless steel and ROHS-certified surface finishes.
Used in PLC-controlled machinery, air-actuated systems, conveyors, pick-and-place arms.
Recommended fittings: Tee connectors, quick couplers, elbow swivel joints
Benefit: Fast installation, minimal leakage, supports modular upgrades
Used in air impact tools, tire inflation lines, pneumatic lifts.
Recommended fittings: Quick-release couplers, adapters
Benefit: Fast tool changes, durable under rough handling
Used in filling machines, bottling lines, and packaging conveyors.
Recommended fittings: Stainless steel push-in fittings, passivated threads
Benefit: Sanitary, corrosion-free, easy to clean
Used in test benches, air-driven analytical devices.
Recommended fittings: PBT straight connectors, nickel-plated brass adapters
Benefit: Lightweight, clean assembly, non-contaminating
| Thread Type | Standard | Compatible Regions |
|---|---|---|
| NPT | National Pipe Taper (60°) | USA, Canada |
| BSPT | British Pipe Taper (55°) | EU, Asia, Australia |
| Metric | ISO Metric Threads | Global industrial machines |
| G (Parallel) | British standard, non-tapered | Europe, legacy systems |
| Metric Sizes | Imperial Sizes |
|---|---|
| 4mm, 6mm, 8mm, 10mm, 12mm | 1/8″, 1/4″, 3/8″, 1/2″ |
Most of our push-in fittings support flexible polyurethane (PU), nylon (PA), or polyethylene (PE) tubing.
Ensure tubing is cut squarely for push-in fittings
Use PTFE tape on male threads to improve sealing
Don’t overtighten metal fittings, especially on soft metals
Use locknuts or collars in high-vibration environments
Inspect O-rings periodically for wear and tear
| Feature | Our Advantage |
|---|---|
| ✅ Material Quality | ROHS-compliant, FDA-grade optional |
| ✅ Full Range of Sizes & Types | From 1/8″ to 1/2″, BSP/NPT/Metric available |
| ✅ Surface Treatments | Nickel, chrome, anodized, passivated options |
| ✅ Custom OEM Services | Engraved logo, custom threads, packaging |
| ✅ Fast Delivery | Stock available for common sizes |
| ✅ Strict QC | 100% pressure testing before shipment |
